BASIC OPERATION
77
Internal
Storage
1. Press right arrow button to enter the
list of 10 groups. Rotate the scroll
wheel (Encode) to select target file.
Also rotate the scroll wheel (Encode)
to enter the flash drive when
necessary.
2. Press F3 (Save) button to save the
temporary data into the
corresponding file.
3. Press F4 (Recall) button to save the
record data of file into the
temporary storage for further saving
into flash drive later.
Flash
drive
operation
descriptio
n
Note:
Type/*.CSV/ *.REC/New
File/Select buttons appear when
flash drive is selected.
Type is used to select *.CSV and
*.REC file types.
New File is used to create new file.
Select is used to open the required
file folder.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the GW Instek GPP-4323 and is the answer not in the manual?

GW Instek GPP-4323 Specifications

General IconGeneral
Number of Outputs4
Ripple and Noise (CC)≤ 3 mArms
Output Voltage0 to 32 V
Output Current0 to 3 A
Ripple and Noise (CV)≤ 1 mVrms
Load Regulation (CV)≤0.01% + 3mV
Load Regulation (CC)≤0.2% + 3mA
Line Regulation (CV)≤ 0.01% + 2 mV
Line Regulation (CC)≤0.2% + 3mA
Display4.3 inch LCD
InterfaceUSB, RS232
Operating Temperature0 to 40 °C
Storage Temperature-10 to 70 °C
