H.264 4-CH - DVR Remote Controller(Just for Your Reference,Please Accord to the Real Products); Remote Controller Operation

USER MANUAL
8
(1)Video input (2) Video output (3) Audio input/ output (4) USB interface
(5) Network interface (6) RS-485 interface (7) Power interface (8) VGA output
(9) Alarm input/output (10)HDMI interface
2.3 DVR Remote controller(Just for your reference, according to the real products)
Remote controller operation
Serial number
Name
Function
1
Multi-window
button
Same function as Multi-window button on the front
panel
2
Numeric button
Password input/number input/channel switch
3
【Esc】
Same function as【Esc】button on the front panel
4
Direction button
Same function as direction button on the front panel
5
ADD
Input the DVR ID to control it
6
FN
Assistant function
7
Record control
Control the record
8
Record mode
Same function as “Record mode”
