1-3
Item S3100-26T-SI S3100-16T-SI S3100-8T-SI
PoE (as powered
device)
Not supported Not supported Not supported
System power
consumption (full load)
20 W 12 W 10 W
Fan None None None
Operating temperature 0°C to 45°C (30°F to 113°F)
Relative humidity
(noncondensing)
10% to 90%
S3100-C-SI Series
Table 1-4 Technical specifications for the S3100-C-SI series
Item S3100-26C-SI S3100-16C-SI S3100-8C-SI
Physical dimensions
(H × W × D)
42 × 436 × 240 mm
(1.65 × 17.2 × 9.4 in.)
42 × 436 × 200 mm
(1.65 × 17.2 × 7.9 in.)
42 × 326 × 200 mm
(165 × 12.8 × 7.9 in.)
Weight ≤ 3.2 kg (7.1 lb.)
Number of fixed ports
24 × auto-sensing
10/100Base-TX
Ethernet port
16 × auto-sensing
10/100Base-TX
Ethernet port
8 × auto-sensing
10/100Base-TX
Ethernet port
Number of expansion
slots
2 2 1
Number of
management ports
1 × console port
Supported expansion
interface module type
10/100/1000Base- T interface module with max transmission distance of
100 m (328.1 feet)
100Base- SX (SC, 2 km (1.2 mi))
100Base- LX (SC, 15 km (9.3 mi))
100Base- LH40 (SC, 40 km (24.9 mi))
1000Base- SX (SC, 0.5 km (0.3 mi))
1000Base- LX (SC, 10 km (6.2 mi))
1000Base- LH40 (LC, 40 km (24.9 mi))
1000Base- LH70 (LC, 70 km (43.5 mi))
1000Base- STACK (not supported by S3100-8C-SI)
100Base- TX PD (powered device) interface module (only supported by
S3100-16C-SI DC-powered switch and S3100-8C-SI DC-powered switch)
1000Base- PX10 (SC, 10 km (6.2 mi))
1000Base- PX20 (SC, 20 km (12.4 mi))
100Base-LX-SM1310-BIDI (SC, 15 km (9.3 mi))
100Base-LX-SM1550-BIDI (SC, 15 km (9.3 mi))
