3-23
The following section describes the procedures to connect optical fiber to an ONU card. The procedures
also apply to other subcards.
Step 1: Remove the protective cap from the optical connector of the fiber.
Step 2: Remove the protective cap from the PON interface of the ONU subcard.
Step 3: Plug the optical connector into the PON interface of the ONU subcard.
Installation Verification
After completing the installation, check that:
z The correct power is used.
z The grounding cable is connected.
z The power cable is properly connected.
z All the interface cables are cabled indoors. If there is any cable wired outdoors, verify that socket
strip with lightning protection and lightning arresters for network ports have been properly
connected.
