H3C S3100 Series Installation Manual

3-3
Table 3-3 Selection of mounting ear for S3100 Series Ethernet Switches
Model
Physical dimensions (H
× W × D)
Configuration
type of front
mounting ear
Configuration
type of rear
mounting ear
S3100-26T-SI
S3100-26C-SI
S3100-26C-EPON-EI
42 × 436 × 240 mm
(1.65 × 17.2 × 9.4 in.)
Standard
S3100-16T-SI
S3100-16C-SI
S3100-16C-EPON-EI
42 × 436 × 200 mm
(1.65 × 17.2 × 7.9 in.)
Standard
S3100-8T-SI
S3100-8C-SI
S3100-8C-EPON-EI
42 × 326 × 200 mm
(1.65 × 12.8 × 7.9 in.)
Optional
—
S3100-52TP-SI
43.6 × 440 × 230 mm
(1.7 × 17.3 × 9.1 in.)
Standard
S3100-26TP-SI
S3100-26TP-EI
43.6 × 440 × 160 mm
(1.7 × 17.3 × 6.3 in.)
Standard
S3100-16TP-SI
S3100-16TP-EI
43.6 × 360 × 160 mm
(1.7 × 14.2 × 6.3 in.)
Optional
S3100-8TP-SI
S3100-8TP-EI
43.6 × 230 × 160 mm
(1.7 × 9.1 × 6.3 in.)
Optional
—
S3100-26TP-PWR-EI
43.6 × 440 × 420 mm
(1.7 × 17.3 × 16.5 in.)
Standard Standard
S3100-16TP-PWR-EI
43.6 × 300 × 260 mm
(1.7 × 11.8 × 10.2 in.)
Optional —
S3100-8TP-PWR-EI
43.6 × 300 × 220 mm
(1.7 × 11.8 × 8.7 in.)
Optional —
Introduction to guide rail
Figure 3-3 shows the appearance of a guide rail.
