1-4
Item S3100-26C-SI S3100-16C-SI S3100-8C-SI
Power system
Both DC-powered switch and AC-powered switch are available to each
model. The AC-powered switch supports only AC input, and the
DC-powered switch supports only DC input.
AC input:
z Rated voltage range: 100 VAC to 240 VAC, 50 Hz/60 Hz
z Input voltage range: 90 VAC to 264 VAC, 47 Hz to 63 Hz
DC input:
z Rated voltage range: –48 VDC to –60 VDC
z Input voltage range: –36 VDC to –72 VDC
PoE (as powered
device)
Not supported
Supported by
DC-powered switch
Supported by
DC-powered switch
System power
consumption (full load)
20 W 12 W 10 W
Fan None None None
Operating temperature 0°C to 45°C (30°F to 113°F)
Relative humidity
(noncondensing)
10% to 90%
z Only S3100-16C-SI DC-powered switch or S3100-8C-SI DC-powered switch supports 100Base-
TX PD interface module. Notice that S3100-16C-SI DC-powered switch can accommodate only
one PD interface module.
z The PoE configuration is on the remote power source device, on the powered device
(S3100-16C-SI DC-powered switch or S3100-8C-SI DC-powered switch), you only need to insert
the cable into the interface of 100Base- TX PD.
z BIDI interface card must be used in couple; that is, if the local end uses 100Base-LX-SM1310-BIDI,
the remote end needs to use 100Base-LX-SM1550-BIDI.
z An S3100-16C-SI or S3100-26C-SI switch can accommodate only one ONU module
(1000Base-PX10/20). For details about ONU modules, refer to section “
ONU Modules”.
S3100-EI Series Ethernet Switches
S3100-TP-EI Series
Table 1-5 Technical specifications for the S3100-TP-EI series
Item S3100-26TP-EI S3100-16TP-EI S3100-8TP-EI
Physical dimensions
(H × W × D)
43.6 × 440 × 160 mm
(1.7 × 17.3 × 6.3 in.)
43.6 × 360 × 160 mm
(1.7 × 14.2 × 6.3 in.)
43.6 × 230 × 160 mm
(1.7 × 9.1 × 6.3 in.)
Weight ≤ 3 kg (6.6 lb.)
