H3C S3100 Series Installation Manual

1-5
Item S3100-26TP-EI S3100-16TP-EI S3100-8TP-EI
24 × auto-sensing
10/100Base-TX
Ethernet port
2 × 1000 Mbps Combo
port
16 × auto-sensing
10/100Base-TX
Ethernet port
2 × 1000 Mbps Combo
port
8 × auto-sensing
10/100Base-TX
Ethernet port
1 × 1000 Mbps Combo
port
Number of fixed ports
Note: A 100/1000Base-X SFP port and a corresponding auto-sensing
10/100/1000Base-T Ethernet port form a Combo port. For each Combo
port, either the SFP port or the corresponding 10/100/1000Base-T
Ethernet port can be used at a time.
Number of
management ports
1 × console port
Power system
Both DC-powered switch and AC-powered switch are available to each
model. The AC-powered switch supports only AC input, and the
DC-powered switch supports only DC input.
AC input:
z Rated voltage range: 100 VAC to 240 VAC, 50 Hz/60 Hz
z Input voltage range: 90 VAC to 264 VAC, 47 Hz to 63 Hz
DC input:
z Rated voltage range: –48 VDC to –60 VDC
z Input voltage range: –36 VDC to –72 VDC
PoE (as powered
device)
Not supported Not supported Not supported
System power
consumption (full load)
17W 15W 12W
Fan None None None
Operating temperature 0°C to 45°C (30°F to 113°F)
Relative humidity
(noncondensing)
10% to 90%
S3100-TP-PWR-EI Series
Table 1-6 Technical specifications for the S3100-TP-PWR-EI series
Item S3100-26TP-PWR-EI S3100-16TP-PWR-EI S3100-8TP-PWR-EI
Physical dimensions
(H × W × D)
43.6 × 440 × 420 mm
(1.7 × 17.2 × 10.2 in.)
43.6 × 300 × 260 mm
(11.8 × 8.7 × 1.7 in.)
43.6 × 300 × 220 mm
(1.7 × 9.1 × 7.9 in.)
Weight < 6.5 kg (14.3 lb.) < 3.5 kg (7.7 lb.) < 3.0 kg (6.6 lb.)
24 × auto-sensing
10/100Base- TX
Ethernet port
2 × 1000 Mbps Combo
port
16 × auto-sensing
10/100Base- TX
Ethernet port
2 × 1000 Mbps Combo
port
8 × auto-sensing
10/100Base- TX
Ethernet port
1 × 1000 Mbps
Combo port
Number of fixed ports
Note: A 100/1000Base-X SFP port and a corresponding auto-sensing
10/100/1000Base-T Ethernet port form a Combo port. For each Combo
port, either the SFP port or the corresponding 10/100/1000Base-T
Ethernet port can be used at a time.
Number of
management ports
1 × console port
