1-6
Item S3100-26TP-PWR-EI S3100-16TP-PWR-EI S3100-8TP-PWR-EI
Power system
S3100-26TP-PWR-EI Ethernet switches support AC input and DC input.
S3100-16TP-PWR-EI/S3100-8TP-PWR-EI Ethernet switches support
only AC input.
AC input:
z Rated voltage range: 100 VAC to 240 VAC, 50 Hz/60 Hz
z Input voltage range: 90 VAC to 264 VAC, 47 Hz to 63 Hz
DC input:
z Rated voltage range: –52 VDC to –56 VDC
System
power
consumption
(full load)
AC input: 465 W
DC input: 400 W
160 W 95 W
All ports
serve as
PoE
ports
PoE power
maximum
15.4 W × 24 15.4 W × 8 15.4 W × 4
Number of fans 4 2 2
Operating temperature 0°C to 45°C (30°F to 113°F)
Relative humidity
(noncondensing)
10% to 90%
S3100-26TP-PWR-EI, S3100-16TP-PWR-EI, and S3100-8TP-PWR-EI Ethernet switches provide an
over-temperature protection mechanism. When the internal temperature exceeds 65°C (149°F), they
will stop providing power from all ports. When the temperature is below 60°C (140°F), they will continue
to provide power from all ports.
S3100-C-EPON-EI Series
Table 1-7 Technical specifications for the S3100-C-EPON-EI series
Item S3100-26C-EPON-EI S3100-16C-EPON-EI S3100-8C-EPON-EI
Physical
dimensions (H × W
× D)
42 × 436 × 240 mm
(1.65 × 17.17 × 9.45 in.)
42 × 436 × 200 mm
(1.65 × 17.17 × 7.87 in.)
42 × 326 × 200 mm
(1.65 × 12.83 × 7.87 in.)
Weight ≤ 3.2 kg (7.05 lb.) ≤ 3.2 kg (7.05 lb.) ≤ 3.2 kg (7.05 lb.)
Number of fixed
ports
24 × 10/100Base-TX
ports
1 × 1000 Mbps PON
port
16 × 10/100Base-TX
ports
1 × 1000 Mbps PON
port
8 × 10/100Base-TX
ports
1 × 1000 Mbps PON
port
Number of
expansion slots
1 Disabled —
Optional module
ONU module
(1000Base-PX20)
— —
Number of
management ports
1 console port
