1-2
Model S3100-52TP- SI S3100-26TP- SI S3100-16TP-SI S3100-8TP-SI
24 × auto-sensing
10/100Base-TX
Ethernet port
2 × 1000 Mbps
Combo port
16 x auto-sensing
10/100Base-TX
Ethernet port
2 x 1000Mbps
Combo port
8 × auto-sensing
10/100Base-TX
Ethernet port
1 × 1000 Mbps
Combo port
Number of fixed
ports
48 x auto-sensing
10/100Base-TX
Ethernet port
2 x auto-sensing
10/100/1000Base
-T Ethernet port
2 x
100/1000Base-X
SFP port
Note: A 100/1000Base-X SFP port and a corresponding
auto-sensing 10/100/1000Base-T Ethernet port form a
Combo port. For each Combo port, either the SFP port or
the corresponding 10/100/1000Base-T Ethernet port can
be used at a time.
Number of
management
port
1 x console port
Power system
AC input:
z Rated voltage range: 100 VAC to 240 VAC, 50 Hz /60 Hz
z Input voltage range: 90 VAC to 264 VAC, 47 Hz to 63Hz
PoE (as powered
device)
Not supported Not supported Not supported Not supported
System power
consumption (full
load)
24 W 16 W 14 W 10W
Fan None None None None
Operating
temperature
0°C to 45°C (30°F to 113°F)
Relative humidity
(non-
condensing)
10% to 90%
S3100-T-SI Series
Table 1-3 Technical specifications for the S3100-T-SI series
Item S3100-26T-SI S3100-16T-SI S3100-8T-SI
Physical dimensions
(H × W × D)
42 × 436 × 240 mm
(1.65 × 17.2 × 9.4 in.)
42 × 436 × 200 mm
(1.65 × 17.2 × 7.9 in.)
42 × 326 × 200 mm
(1.65 × 12.8 × 7.9 in.)
Weight ≤ 3.2 kg (7.1 lb.)
Number of fixed ports
24 × auto-sensing
10/100Base-TX
Ethernet port
2 ×
10/100/1000Base-T
Ethernet port
16 × auto-sensing
10/100Base-TX
Ethernet port
1 ×
10/100/1000Base-T
Ethernet port
8 × auto-sensing
10/100Base-TX
Ethernet port
1 ×
10/100/1000Base-T
Ethernet port
Number of
management ports
1 × console port
Power system
Only AC input is supported.
Rated voltage range: 100 VAC to 240 VAC, 50 Hz/60 Hz
Input voltage range: 90 VAC to 264 VAC, 47 Hz to 63 Hz
