1-7
Item S3100-26C-EPON-EI S3100-16C-EPON-EI S3100-8C-EPON-EI
Power system
AC input:
z Rated voltage range: 100 VAC to 240 VAC, 50 Hz/60 Hz
z Input voltage range: 90 VAC to 264 VAC, 47 Hz to 63 Hz
PoE (as powered
device)
Not supported Not supported Not supported
System power
consumption (full
load)
20 W 13 W 11 W
Number of fans 1 None None
Operating
temperature
0°C to 45°C (30°F to 113°F)
Relative humidity
(non-condensing)
10% to 90%
Introduction to S3100-SI Series Ethernet Switches
S3100-52TP-SI
Front panel
Each S3100-52TP-SI Ethernet switch provides forty-eight auto-sensing 10/100Base-TX Ethernet ports,
two auto-sensing 10/100/1000Base-T Ethernet ports, and two 100/1000Base-X SFP ports on its front
panel.
Figure 1-1 shows the front panel of an S3100-52TP-SI Ethernet switch.
Figure 1-1 Front panel of an S3100-52TP-SI Ethernet switch
(1) Auto-sensing 10/100Base-TX port (2) Auto-sensing 10/100/1000Base-T port
(3) 100/1000Base-X SFP port (4) Power LED (Power)
(5) SFP port Speed LED (6) SFP port LINK/ACT LED
(7) 10/100/1000Base-T port LINK/ACT LED (8) 10/100/1000Base-T port Speed LED
(9) 10/100Base-TX port Speed LED (10) 10/100Base-TX port LINK/ACT LED
