H3C S3100 Series Installation Manual

1-33
Port Status LED
Table 1-12 describes the Link/Act LED of the auto-sensing 10/100Base-TX port.
Table 1-12 Description of the Link/Act LED on the S3100-TP-SI and S3100-TP-EI series
LED Status Description
ON The port is connected properly.
Blinking
The port is in the active state and there is traffic
on the port.
Link/Act LED (green)
OFF
The port is not connected or is incorrectly
connected.
Table 1-13 describes the Speed LED of the 10/100Base-TX port.
Table 1-13 Description of the 10/100Base-TX port Speed LED of the S3100-TP-SI and S3100-TP-EI
series
LED Status Description
ON The port is operating at 100 Mbps.
Auto-sensing 10/100Base-TX
port speed LED (green)
OFF The port is operating at 10 Mbps.
For the description of the Link/Act LED of the Combo port on the S3100-TP-SI and the S3100-TP-EI
series, see
Table 1-12. When the port is connected correctly, the Speed LED indicates the operating
speeds of the Combo port, as shown in
Table 1-14.
Table 1-14 Description of the Combo port Speed LED of the S3100-TP-SI and the S3100-TP-EI series
LED Operating port Status Description
Connected to a
1000 Mbps optical
module
ON
The port is operating at
1000 Mbps.
100/1000Base-X
SFP port
Connected to a
100 Mbps optical
module
OFF
The port is operating at 100
Mbps.
ON
The port is operating at
1000 Mbps.
Combo port
Speed LED
(green)
Auto-sensing 10/100/1000Base-T port
OFF
The port is operating at
10/100 Mbps.
For the description of the Link/Act LED of the 100/1000Base-X SFP port and Auto-sensing
10/100/1000Base-T port on the S3100-52TP-SI, see
Table 1-12. When the port is connected correctly,
the Speed LED indicates the operating speeds of the port, as shown in
Table 1-15.
