H3C S3100V2 Series User Manual

50
Item S3100V2-26TP-SI S3100V2-16TP-SI S3100V2-8TP-SI
Chassis leakage
current compliance
UL60950-1, EN60950-1, IEC60950-1, GB4943
S3100V2-EI Switch Series technical specifications
The H3C S3100V2-EI Switch Series includes the S3100V2-TP-EI switches and the S3100V2-TP-PWR-EI
switches.
S3100V2-TP-EI switches technical specifications
Table 14 S3100V2-TP-EI switches technical specifications
Item S3100V2-26TP-EI S3100V2-16TP-EI S3100V2-8TP-EI
Dimensions (H × W
× D)
43.6 × 440 × 160 mm
(1.72 × 17.32 × 6.30 in)
43.6 × 360 × 160 mm
(1.72 × 14.17 × 6.30 in)
43.6 × 230 × 160 mm
(1.72 × 9.06 × 6.30 in)
Weight ≤ 3 kg (6.61 lb)
24 10/100Base-TX
auto-sensing Ethernet ports
2 combo interfaces
(numbered 25 and 26)
16 10/100Base-TX
auto-sensing Ethernet ports
2 combo interfaces
(numbered 17 and 18)
8 10/100Base-TX
auto-sensing Ethernet ports
1 combo interface
(numbered 9)
Fixed ports
NOTE:
Each combo interface has one 100/1000Base-X fiber SFP port and one
10/100/1000Base-T auto-sensing copper Ethernet port. These two ports share one port
name and port view and cannot work simultaneously. When you activate one port (by
using the combo enable { copper | fiber } command), the other port automatically shuts
down.
Management ports 1 console port
Input voltage
(AC-input)
• Rated voltage: 100 VAC to 240 VAC, 50 or 60 Hz
• Max voltage: 90 VAC to 264 VAC, 47 Hz to 63 Hz
Input current 0.4 A 0.4 A 0.4 A
Melting current of
power supply fuse
2 A 2 A 2 A
Power consumption
(minimum hardware
and software
configuration)
7 W 7 W 7 W
Power consumption
(full hardware
configuration)
13 W 12 W 9 W
Max thermal output 44.3573 BTU/h 40.9452 BTU/h 30.7089 BTU/h
Cooling system Fanless, natural heat dissipation
Operating
temperature
0°C to 45°C (32°F to 113°F)
