H3C S3100V2 Series User Manual

54
10/100/1000Base-T Ethernet port
All S3100V2 switches provide 10/100/1000Base-T auto-sensing Ethernet ports on their front panels.
Table 19 10/100/1000Base-T Ethernet port specifications
Item Specification
Connector type RJ-45
Interface attributes
• 10 Mbps, full/half duplex
• 100 Mbps, full/half duplex
• 1000 Mbps, full duplex
• MDI/MDI-X, auto-sensing
Max transmission distance 100 m (328.08 ft)
Transmission medium Category-5 (or above) twisted pair cable
Standards IEEE 802.3i, 802.3u, 802.3ab
100/1000Base-X SFP port
All S3100V2 switches provide 100/1000Base-X SFP ports on their front panels, and you can install the
hot swappable 100 Mbps or 1000 Mbps SFP transceiver modules in Table 20 in
the ports for long
distance connections.
Table 20 SFP transceiver modules available for the H3C S3100V2 Switch Series
Category Transceiver module
Central
wavelength
Connector
Fiber
Max
transmission
distance
50/125 μm
multimode
optical fiber
550 m
(1804.46 ft)
SFP-GE-SX-MM850-A 850 nm
62.5/125 μm
multimode
optical fiber
275 m
(902.23 ft)
1000 Mbps
transceiver
modules
SFP-GE-LX-SM1310-A 1310 nm
LC
9/125 μm
single mode
optical fiber
10 km (6.21
miles)
SFP-GE-LX-S
M1310-BIDI
TX: 1310 nm
RX: 1490 nm
1000 Mbps
BIDI
transceiver
modules
SFP-GE-LX-S
M1490-BIDI
You must
use these
two
transceiver
s in pairs.
TX: 1490 nm
RX: 1310 nm
LC
9/125 μm
single mode
optical fiber
10 km (6.21
miles)
SFP-FE-SX-MM1310-A
62.5/125 μm
multimode
optical fiber
2 km (1.24
miles)
100 Mbps
SFP
transceiver
modules
SFP-FE-LX-SM1310-A
1310 nm LC
9/125 μm
single mode
optical fiber
15 km (9.32
miles)
