19
Figure 27 Viewing storage controller information
Table 3 Parameter description
Hardware Revision Hardware version.
Replacing the storage controller
1. Replace the storage controller.
For more information, see the storage controller replacement procedure in the user guide for
the server.
2. Configure the new storage controller. Make sure the replaced and newly installed storage
controllers operate in the same mode and have the same firmware version.
Replacing a storage controller in legacy mode
Prerequisites
1. Access the storage controller configuration screen.
2. View the operating mode and firmware version of the storage controller to be replaced.
3. View the first boot option.
4. On the screen as shown in Figure 28, select Logical Device Configuration, and press Enter.
