H3C WX3500H Series Installation Guide

34
Technical specifications
WX3508H
Table 13 WX3508H technical specifications
Item Specification
Console port One, 9600 bps (default) to 115200 bps
Gigabit Ethernet port 8 × 100/1000BASE-T autosensing Ethernet copper port
SFP port
2 × 1000BASE-X SFP port. Each form a combo interface with
the 100/1000BASE-T autosensing Ethernet port marked with
the same number.
Memory 2GB DDR3
Storage media 1GB NAND flash
Dimensions (H × W × D) (excluding rubber
feet and mounting brackets)
43.6 × 330 × 230 mm (1.72 × 12.99 × 9.06 in)
AC power module Rated voltage range: 100 to 240 VAC @ 50/60 Hz
System power consumption 20 W to 32 W
Weight 2 kg (4.41 lb)
Operating temperature 0°C to 45°C (32°F to 113°F)
Operating humidity 5% RH to 95% RH, noncondensing
WX3510H
Table 14 WX3510H technical specifications
Item Specification
Console port One, 9600 bps (default) to 115200 bps
Gigabit Ethernet port 8 × 100/1000BASE-T autosensing Ethernet copper port
SFP port 8 × 100BASE-FX/1000BASE-X SFP port
Memory 2 × 2GB DDR3
Storage media 4GB CF Card
Dimensions (H × W × D) (excluding rubber
feet and mounting brackets)
43.6 × 440 × 420 mm (1.72 × 17.32 × 16.54 in)
AC power module Rated voltage range: 100 to 240 VAC @ 50/60 Hz
DC power module Rated voltage range: –48 VDC to –60 VDC
System power consumption 86 W to 160 W
Weight (excluding power modules and hard
disk)
5.4 kg (11.90 lb)
Operating temperature 0°C to 45°C (32°F to 113°F)
Operating humidity 5% RH to 95% RH, noncondensing
