Appendix B LEDs
LEDs
Figure 31 WX3508H LEDs
(1) 100/1000BASE-T autosensing Ethernet copper port status LEDs
(2) 1000BASE-X SFP port status LEDs (3) System status LED (SYS)
Figure 32 WX3510H LEDs
(1) 100/1000BASE-T autosensing Ethernet copper port status LEDs
(2) 100BASE-FX/1000BASE-X SFP port status LEDs
(3) Power module 1 status LED (PWR1) (4) Power module 2 status LED (PWR2)
(5) System status LED (SYS) (6) Expansion card status LED (MOD)
2 31
1 2
3
4
5
6
