36
AC power module
Table 17 AC power module specifications
Item Specification
Model PSR150-A1
Rated input voltage range 100 VAC to 240 VAC @ 50/60 Hz
Rated power capacity 150 W
DC power module
Table 18 DC power module specifications
Item Specifications
Model PSR150-D1
Rated input voltage range –48 VDC to –60 VDC
Rated power capacity 150 W
Transceiver module, fiber connector, and optical
fiber views
To connect a fiber port on the device, use an SFP or SFP+ transceiver module and an optical fiber
with LC connectors.
Figure 28 SFP transceiver module
