Hach CL17 User Manual

Page 18
Sample Conditioning
54400_install.fm
Section 1
Table 1 Sample Conditioning Parts List
Item Description Qty Catalog Number
1 Clamp, Conduit Hanger, 1-inch 4 47349-00
2 Coupling, 1-inch, SCH 40, PVC pipe 1 54175-00
3 Coupling, ½-inch FPT x ½ FPT PVC 1 54176-00
4 Fitting, Reduce Bushing, PVC, Hex 2 23002-00
5 Fitting, Stem Adapter, ½-inch O.D., ¼ NPT 1 54180-00
6 Fitting, Tee, 1-inch x 1-inch 1 46622-00
7 Fitting, Tube, Connector, Male (¼-inch tubing) 3 51246-00
8 Fitting, Tube, Connector, Male (½-inch tubing) 2 51262-00
9 Fitting, Tube, ½-inch O.D. x ½-inch Male NPT 1 54178-00
10 Fitting, Tube, ½-inch O.D. Union Elbow 1 54179-00
11 Fitting, Tube, ½-inch O.D., Union Straight 1 54181-00
12 Pipe, Pre-cut Drain, 1-inch Diameter, PVC 1 51239-00
13 Pipe, Drain, Clear 1 54174-00
14
Strainer, Y-body 1 54183-00
Filter, 40-mesh Screen (provided with strainer and in Maintenance Kit, 55165-00) 1 54184-00
15 Teflon
®
, Thread Tape, ¼-inch wide 1 70608-24
16 Tubing, Polyethylene, 0.250 O.D., 0.040 W, Black 15 feet 30616-00
17 Tubing, Polyethylene, 0.500 O.D., 0.062 W, Black 10 feet 51159-00
18 Valve, Ball, PVC, ½ NPT, PVC 1 54177-00
19 Valve, Ball, PVC, ¼ NPT, PVC 1 51395-00

Hach CL17 Specifications

General

Power Requirements	100-240 V AC, 50/60 Hz
Outlet Pressure	Atmospheric
Measurement Method	Colorimetric DPD method
Sample Interval	2.5 minutes
Operating Temperature	5 - 40 °C (41 - 104 °F)
Parameter	Free or Total Chlorine
Operating Humidity	5 - 95% non-condensing
Sample Temperature	0 to 40°C (32 to 104°F)
Sample Flow Rate	200 to 500 mL/min
Power Consumption	Approximately 50 W
Output	4-20 mA, RS-232
Relays	Two relays
Enclosure	NEMA 4X
Resolution	0.01 mg/L
Accuracy	±5% or ±0.03 mg/L (whichever is greater)
