54400_maintain.fm Unscheduled Maintenance
Figure 20 Removing the stir bar
3.2.2 Cleaning the Instrument Enclosure
With the enclosure securely latched, use a soft cloth and a mild
detergent to wipe the outside of the enclosure. Do not allow moisture to enter
the enclosure.
3.2.3 Cleaning the Colorimeter
The colorimeter measuring cell may collect sediment or develop a film growth
on the inside walls. Cleaning with an acid solution and a cotton swab on a
monthly basis is recommended. Depending on sample conditions, it may be
necessary to clean the cell more often.
