54400_maintain.fm Unscheduled Maintenance
Figure 21 Cleaning the Colorimeter
3.2.4 Replacing the Sample Conditioning Filter
To insert the filter into the housing:
1. Isolate the filter by turning the valves on each side to OFF.
2. Unscrew the top of the filter housing. See Figure 6 on page 19.
3. Insert the filter element and push until it stays in place.
4. Replace the filter housing top.
3.2.5 Reagent Spill Clean Up Instructions
Wipe up spills with a clean, disposable wipe and discard according to
applicable Federal, State, and Local regulations.
