24
Installation
Figure 6 Wall and pipe mount connection panel
1. Power cable
2. USB-B 4 pin connector (reserved
for Hach service technicians)
3. Ethernet cable gland
4. K1200 Sensor connection
5. TC Sensor connection
6. USB-A host connector for mass storage device
7. External pressure sensor connection
8. Input/Output 2 cable gland
9. Input/Output 1 cable gland
10. Keylock
