Communication Menu
K1200 gas sensor calibration report example
Calibration report nb 1
Calibration mode . . . . . . . . . . . .Manual high level adjustment
Date (yy.mm.dd - hh:mm) . . . . .15.02.17 - 18:40
Operator . . . . . . . . . . . . . . . . . .jp
Operator ID . . . . . . . . . . . . . . . .3
Cal. sample . . . . . . . . . . . . . . . .In line sample
Medium . . . . . . . . . . . . . . . . . . .Liquid
Gas unit. . . . . . . . . . . . . . . . . . .ppb
Liquid. . . . . . . . . . . . . . . . . . . . .Beer
Ref. value . . . . . . . . . . . . . . . . .1.500000
Cal. coefficient Phi0(Tcal) . . . . .25.974°
Cal. coefficient Tcal . . . . . . . . . .24.41°C
Cal. coefficient Ksv(25°C) . . . . .-0.1312 mbar-1
Cal. coefficient Tcal.Inst. . . . . . .25.20°C
Standard deviation . . . . . . . . . .0.003 mbar
Fluor. amplitude. . . . . . . . . . . . .0.834 V
Interferences . . . . . . . . . . . . . . .Disable
Temperature . . . . . . . . . . . . . . .20.1 °C
Calibration duration . . . . . . . . . .3 mn
TC gas sensor calibration report example
Calibration report nb 1
Date (yy.mm.dd - hh:mm) . . . . .15.02.18 - 15:20
Operator . . . . . . . . . . . . . . . . . .jp
Operator ID . . . . . . . . . . . . . . . .3
Calibration coefficient . . . . . . . .18.23 mV/bar
Ratio with ideal membrane . . . .107.22 %
Ratio with last calibration . . . . .106.32 %
Stability . . . . . . . . . . . . . . . . . . .0.337 %
Calibration value . . . . . . . . . . . .965.000000
Gas unit. . . . . . . . . . . . . . . . . . .mbar
Gas phase. . . . . . . . . . . . . . . . .Gas
Liquid. . . . . . . . . . . . . . . . . . . . .Water
Interferences . . . . . . . . . . . . . . .Disable
Temperature . . . . . . . . . . . . . . .26.44 °C
Barometric pressure . . . . . . . . .0.962 bar
External pressure . . . . . . . . . . .0.976 bar
Sensor slope . . . . . . . . . . . . . . .18.797 mV/s
Barometric sensor calibration report example
Calibration report nb 1
Date (yy.mm.dd - hh:mm) . . . . .15.02.16 - 20:38
Operator . . . . . . . . . . . . . . . . . .jp
Operator ID . . . . . . . . . . . . . . . .3
Former barometric pressure . . .0.970 bar
New Barometric pressure . . . . .0.971 bar
External pressure calibration report example
Calibration report nb 1
Date (yy.mm.dd - hh:mm) . . . . .15.02.16 - 21:37
Operator . . . . . . . . . . . . . . . . . .Armstrong
Operator ID . . . . . . . . . . . . . . . .1007
Nb of cal. points. . . . . . . . . . . . .1
New slope . . . . . . . . . . . . . . . . .45.454545 [bar/V]
New offset . . . . . . . . . . . . . . . . .0.103926 [bar]
Former P1 value . . . . . . . . . . . .0.973 bar
New P1 value . . . . . . . . . . . . . .0.972 bar
