Hach ORBISPHERE 51 Series User Manual

84
Communication Menu
Commands
The “Command Output Buffer” is formatted as follows:
The “Command Input Buffer” is located just after the measurement data and is formatted as
follows:
The following commands are available:
• Change product
• Set channel hold status
Change product command - output
Change product command - input
Name Type Size Offset
Output command toggle (OCT) Output byte 8 bits 0
Output command ID (OCI) Output byte 8 bits 1
Output command data byte 1 (OCD1) Output byte 8 bits 2
Output command data byte 2 (OCD2) Output byte 8 bits 3
Output command data byte 3 (OCD3) Output byte 8 bits 4
Output command data byte 4 (OCD4) Output byte 8 bits 5
Name Type Size
Offset
Channel 1
Offset
Channel 2
Offset
Channel 3
Input command toggle (ICT) Input byte 8 bits 28 51 74
Input command status (ICS) Input byte 8 bits 29 52 75
Input command data byte 1 (ICD1) Input byte 8 bits 30 53 76
Input command data byte 2 (ICD2) Input byte 8 bits 31 54 77
Input command data byte 3 (ICD3) Input byte 8 bits 32 55 78
Input command data byte 4 (ICD4) Input byte 8 bits 33 56 79
Name Value Comment
OCT 1-2
OCI 1 Command ID
OCD1 0
Channel number:
0 = Channel 1
1 = Channel 2
OCD2 0-99 Product number
OCD3 0-1
Erase measurement files:
0 = Never erase the measurement files.
1 = Erase measurement file if necessary (e.g. gas unit changes)
OCD4 Not used
Name Value Comment
ICT 1-2
ICS 0-3
0 = OK
1 = Unknown command ID
2 = Invalid parameter (e.g. invalid channel no or product number)
3 = Execution failure
ICD1 Not used
ICD2 Not used
ICD3 Not used
ICD4 Not used
