TJA670 domovea Basic
TJA470 domovea Expert
6.4 Measures
6.4.1 Measures
The domovea energy display function responds to a growing desire to reduce energy needs. After the data is acquired
by the different KNX products, it is transmitted to the domovea server via the KNX TP bus.
The domovea server and software archives this data, which will, after processing, be displayed on a viewing device
(tablet, smartphone, PC, etc.)
The maximum number of Measures devices permitted is 100.
A Measures device can be added:
- Automatically: Using the configuration tool, the system automatically recognises the product. The different
devices are thus created.
- Manually: by adding an Energy device (electricity, gas or water)
To create a device, please refer to chapter 6.2.1 Devices
Depending on the type of device, it is possible to assign a subscription.
For more information, please see tutorial 15 - Configure a Hager Energy Meter with easytool and
domovea at www.hager.com/domovea.
6.4.2 Subscriptions
A subscription defines the cost of power consumptions for a given installation. It is comprised of one or more tariffs,
which give the cost according to a given period (day, hour, etc.). The maximum number of permitted subscriptions is
10.
Click on new in the Subscriptions section to create a new subscription.
• select the type of subscription (electric – water - gas),
• rename the subscription directly in the field on the top right.
You can add a description if necessary.
• select consumption or production depending on the value of the subscription,
• click on Use a subscription template to select a pre-defined subscription.
Or
• click on Add a tariff to manually define the type of subscription,
• add other tariffs if required.
For more information, please see tutorial 16 - Set up energy tariffs to visualize the consumption in
domovea at www.hager.com/domovea.
