Hägglunds CMp - Ordering Code; S-Link Hardware Package (SLHP)

10/64 CMp | Ordering code
Bosch Rexroth AB, RE 15409 Version 08.2022,
4 Ordering code
In order to identify Hägglunds equipment exactly, the following ordering code is
used. These ordering codes should be stated in full in all correspondence e.g.
when ordering spare parts. The order code is needed to specify the package
contents and to simplify the handling during the order process.
4.1 S-Link Hardware Package (SLHP)
The order code for the main article contains information about the monitored drive
system. It shows the number of actuators (hydraulic motors), number of Drive
Units (PEC, PAC, DUe, DUc) and the number of additional sensors in the package.
Example:
SLHP 1 01 1 00 0025 00 0
01 02 03 04 05 06 07 08
01 Type of package
S-Link Hardware Package
SLHP
02 No. of machines that is monitored
None
0
One machine
1
Two machines
2
03 No. of actuators
None
00
One motor
01
Two motors
02
04 No. of Drive Units
None
0
One DU
1
Two DU
2
05 No. of sensors
None
00
Number of sensors
01-99
06 ID number
Assigned during engineering
XXXX
07 Special design
Standard
00
Special index
01-99
08 ATEX
No
0
