4/64 CMp | About this documentation
Bosch Rexroth AB, RE 15409 Version 08.2022,
1 About this documentation
1.1 Validity of the documentation
This documentation applies to the Hägglunds CMp hardware (S-Link) and is
intended for machine/system manufacturers, tters and service engineers/
technicians.
This documentation contains important information about the safe and appropriate
assembly, transport, commissioning, operation, maintenance, disassembly and
simple troubleshooting of the product.
f Prior to working with the product, read the entire documentation carefully, in
particular the “Safety instructions” chapter.
1.2 Required and additional documentations
f Before commissioning the product, make sure to have received and fully
understood the documentations identied by the book symbol
and observe
the instructions included in these documentations.
Table 1: Required and additional documentations
Title Document number Document type
Order conrmation Contatins the order related technical
data for your CMp hardware package
Order conrmation
1.3 Presentation of information
Consistent safety instructions, symbols, terms and abbreviations are used in the
present documentation to facilitate orientation for the reader and to ensure safe
product handling. The explanations in the following sections will provide for easy
understanding.
1.3.1 Safety messages
This documentation includes safety messages placed before sequential operating
procedures that may involve the risk of personal or property damage. The
described precautionary measures must be observed.
Safety messages are structured as shown below:
SIGNAL WORD
Type and source of risk
Consequences if disregarded
f Precautionary measures
• Warning sign: draws attention to the risk
• Signal word: identies the hazard level
• Type and source of risk: identies the type and source of the hazard
• Consequences: describes what occurs when the safety messages are not
complied with
• Precautions: indicates how the hazard can be avoided
