25
Operation
2.7 Transporting
In order to transport the vehicle on a
loading space, apply the parking brake
and also secure the vehicle using
straps at both front lashing points
(Fig. 8/1) and the two rear lashing
points (Fig. 8/2) which are located in the
wheel case.
2.8 Towing the vehicle
Towing distance: Max. 500 m to move
the machine from the hazard area.
Towing speed: Max. 5 kph. The two
front lashing points (Fig. 8/1) can be
used as towing lugs.
Fig.8
