HAKO 1500 E - Sweeping

26
Operation
3 Operation
3.1 Method of operation
General information
The Hako-Jonas 1500 is a sweeping
vehicle exclusively designed for sweep-
ing up dry and wet waste from floor sur-
faces as in production plants,
warehouses, car parks and pedestrian
precincts.
Sweeping
The side brush (Fig. 9/1) sweeps the
dirt directly into the pick-up path (Fig. 9/
2) of the rotary brush (Fig. 9/2). The ro-
tary brush sweeps the dirt overhead
(Fig. 9/3) into the sweeping container
(Fig. 9/4). The particulate matter (Fig. 9/
5) swirled up is vacuumed up by the
suction turbine (Fig. 9/7) and forced
against the filter (Fig. 9/6) which filters
it. Dirt disposal with the sweeping con-
tainer is realized via hydraulical lift-up
(Fig. 9/8).
Fig.9
