60
Maintenance and Service
5.7.8 Adjusting the sealing strips
Check the sealing strips in the rotary
brush area every week, readjust as
necessary.
1. Park the vehicle on a level area of
floor.
2. Raise the sweepings container.
3. Switch the machine off and apply the
parking brake.
4. The side sealing strips (Fig. 26/2)
and (Fig. 26/5) can be adjusted via
the slots. The sealing strip must
have a clearance of approx. 1 mm to
the floor.
5. The front sealing strip (Fig. 26/3) can
be adjusted using an actuating rod.
The sealing strip must make contact
with the floor and bend slightly to the
rear.
6. The rear sealing strip (Fig. 26/4) can
be adjusted via the slots. The sealing
strip must have a clearance of ap-
prox. 5 mm to the floor.
5.7.9 Changing the sealing strips
Check the sealing strips in the rotary
brush area weekly for signs of wear, re-
adjust as necessary. Replace worn
sealing strips.
1. Park the vehicle on a level area of
floor.
2. Raise the sweepings container.
3. Switch the machine off and apply the
parking brake.
4. Loosen and remove the sealing
strips and replace by new ones. Only
use original spare parts!
5. Adjust the sealing strips, refer to
Section 5.7.8.
