HAKO 1500 E - Battery system; Battery System Overview

50
Maintenance and Service
5.5 Battery system
1 Charge control indicator
2 Battery plug
3 Batteries
4 Water refilling system (option)
5 Connector
6 Brackets
The illustration depicts the PzS
trough battery set 36V/450 Ah
(option). In order to fix the bat-
tery cable, there are two brack-
ets and cable ties enclosed
with the battery set. Insert the
brackets (Fig. 22/6) in the
small battery trough (Fig. 22/
3b), refer to photo.
Fig.22
1
2
5
3a
3b
4
6
3b
