Technical Data
4 Technical Data
Dimensions and weight
Length mm 2260
Width with/without left-hand side brush mm 1320/1360
Height with/without protective roof mm 1751/1985
Dead weight kg 1560
Permissible total weight kg 2350
Driving and sweeping performance
Driving speed - forwards kph 0-8
Driving speed - reverse kph 0-4
Max. sweeping speed kph 8
Theoretical sweeping performance with/without left-hand
side brush
m²/h 10160/7360
Max. driving gradient % 12
Rotary brush
Length / Diameter mm 920/500
Wear limit diameter mm 400
Speed rpm 540 +/-40
Sweeping pattern mm 75 +/-10
