Pro-Stcher Lite for the HQ Simply Sixteen Installaon Instrucons | 15
4. Place the Pro‑Stcher Lite tray assembly (see
Parts List, item E) onto the HQ Simply Sixteen
carriage and place the one new longer screw
and washer into the outside hole (locaon
circled in the image). Note the posion of the
longer circled screw and washer. It goes through
an addional layer of metal bracket requiring it
to be longer.
5. Fasten the tray with the ve remaining new
screws and washers into the outside screw
holes where you originally removed the old
screws.
Install the Y‑Rack
1. Carefully lay the quilng machine on its le side
as shown (looking from the front).
 IMPORTANT: Take care not to put any undue
weight or pressure on the machine encoder,
circled. You may want to carefully place the
two boom wheels just o the front edge of
the table, with a second person holding the
machine.
2. Locate the Y‑rack (see Parts List, item G) and two
mounng screws (see Parts List, item H) for the
HQ Simply Sixteen machine.
