X. Lifting, handling and towing of the forklift truck
Lift the forklift truck
•Tie the steel rope on the lifting hole and counterweight lifting hook at both ends of the beam of
outer mast firmly and lift the forklift truck with the lifting device.
Caution
Do not wind the steel rope around the overhead guard when lifting the forklift truck.
The steel rope and the lifting device must be strong enough to safely support the forklift
truck, because the truck is extremely heavy.
Do not lift the forklift truck with the cab frame (overhead guard).
Do not stand under the forklift truck when lifting it.
Handling
The forklift truck can be used for loading and unloading and short distance transport, but should not
be used for long distance transport. If the forklift truck is transported over a long distance, it should be
handled with a ship, train or vehicle with load capacity of more than 5t. Chock the wheels with
wedges firmly and tie the body down firmly at the same time to protect the truck from sliding during
transport.
Towing
The drag pin under the counterbalance is only suitable for towing forklift trucks and should not be
used to tow other vehicles or items. The drag pin should be pulled out first when commencing towing;
then, the steel rope should be installed, and the drag pin should be reinstalled.
Note: Release the hand brake lever.
Towing method after truck damage:
Release the hand brake lever. Pull the shift lever into the neutral position. Pay attention to traffic
safety and hang the towing sign.
