HANGCHA CPCD15 - Main Technical Performance Parameters

97
XI. Main technical performance parameters
Model
CPCD30-XW43E-RT
CPCD35-XW43E-RT
Rated load lifting
capacity kg
3000
3500
Load center distance
mm
500
500
Max. lift height mm
3000
3000
Free lift height mm
145
145
Max. lift speed, full
load
mm/s
490
430
Dip angle of mast,
forward/backward
10°/12°
10°/12°
Max. running speed,
no load
km/h
26
26
Min. ground
clearance, mm
270
270
Min. outside steering
radius
mm
2900
2900
Max. gradeability, full
load
%
21
20
Wheelbase
mm
1880
1880
Weight
5120
5380
Dimensions
(including forks)
(L×W×H)
4220×1599×2420
4220×1599×2420
Tires (front/rear)
14.5-17-14PR/2
27×10-12-12PR/2
14.5-17-14PR/2
27×10-12-12PR/2
Voltage (V) / Capacity
(Ah)
12/90
12/90
Diesel engine
Model
Cummins QSF2.8T3NA49
Rated
power/rpm
36.5kW/2500r/min
Max.
torque/rpm
186N·m/ 1500 r/min
Displacement
(L)
2.8
