HANGCHA CPCD15 - Page 107

101
Model
CPCD35-XW43C-RT4
CPCD30-XW43C-RT4
Rated load lifting
capacity kg
3500
3000
Load center distance
mm
500
500
Max. lift height mm
3000
3000
Free lift height mm
150
145
Max. lift speed, full
load
mm/s
430
490
Dip angle of mast,
forward/backward
10°/12°
10°/12°
Max. running speed,
no load
km/h
24
25
Min. ground
clearance, mm
245
245
Min. outside steering
radius
mm
3300
3300
Max. gradeability, full
load
%
50
52
Wheelbase
mm
1880
1880
Weight
5600
5340
Dimensions
(including forks)
(L×W×H)
4320×1599×2420
4320×1599×2420
Tires (front/rear)
14.5-17.5-14PR/2
10.0/75-15.3-14PR/2
14.5-17.5-14PR/2
10.0/75-15.3-14PR/2
Voltage (V) /
capacitance (Ah)
12/90
12/90
Diesel engine
Model
Cummins QSF2.8T3NA49
Cummins QSF2.8T3NA49
Rated
power/rpm
36.5kW/2500r/min
36.5kW/2500r/min
Max.
torque/rpm
186N·m/ 1500 r/min
186N·m/ 1500 r/min
Displacement
(L)
2.8
2.8
