HANGCHA CPCD15 - Page 125

119
Model
CPCD30-X2W33E-RT2
CPCD35-X2W33E-RT2
Rated load lifting
capacity kg
3000
3500
Load center distance
mm
500
500
Max. lift height mm
3000
3000
Free lift height mm
145
145
Max. lift speed, full
load
mm/s
490
430
Dip angle of mast,
forward/backward
10°/12°
10°/12°
Max. running speed,
no load
km/h
26
26
Min. ground
clearance, mm
270
270
Min. outside steering
radius
mm
3000
3000
Max. gradeability, full
load
%
55
52
Wheelbase
mm
1880
1880
Weight
5340
5600
Dimensions
(including forks)
(L×W×H)
4320×1599×2420
4320×1599×2420
Tires (front/rear)
14.5-17.5-14PR/2
27×10-12-12PR/2
14.5-17.5-14PR/2
27×10-12-12PR/2
Voltage (V) /
capacitance (Ah)
12/90
12/90
Diesel engine
Model
Yanmar 4TNE98
Rated
power/rpm
42.1kW/2300 r/min
Max.
torque/rpm
196N·m/ 1700 r/min
Displacement
(L)
3.319
