121
Model
CPCD30-X2W98E-RT2
CPCD35-X2W98E-RT2
Rated load lifting
capacity kg
3000
3500
Load center distance
mm
500
500
Max. lift height mm
3000
3000
Free lift height mm
150
150
Max. lift speed, full
load
mm/s
470
450
Dip angle of mast,
forward/backward
10°/12°
10°/12°
Max. running speed,
no load
km/h
25
25
Min. ground
clearance, mm
270
270
Min. outside steering
radius
mm
1850
2850
Max. gradeability, full
load
%
58
54
Wheelbase
mm
1880
1880
Weight
5340
5600
Dimensions
(including forks)
(L×W×H)
4320×1599×2420
4320×1599×2420
Tires (front/rear)
14.5-17.5-14PR/2
27×10-12-12PR/2
14.5-17.5-14PR/2
27×10-12-12PR/2
Voltage (V) /
capacitance (Ah)
12/90
12/90
Diesel engine
Model
Kubota V2607-CR-TE5B
Rated
power/rpm
47.3kW/2400 r/min
Max.
torque/rpm
221.7N·m/ 1500 r/min
Displacement
(L)
2.615
