HANGCHA CPCD15 - Page 129

123
Model
CPCD30-X2G72E-RT2
CPCD35-X2G72E-RT2
Rated load lifting
capacity kg
3000
3500
Load center distance
mm
500
500
Max. lift height mm
3000
3000
Free lift height mm
150
150
Max. lift speed, full
load
mm/s
490
430
Dip angle of mast,
forward/backward
10°/12°
10°/12°
Max. running speed,
no load
km/h
26
26
Min. ground
clearance, mm
270
270
Min. outside
steering radius
mm
1850
2850
Max. gradeability,
full load
%
55
52
Wheelbase
mm
1880
1880
Weight
5340
5600
Dimensions
(including forks)
(L×W×H)
4320×1599×2420
4320×1599×2420
Tires (front/rear)
14.5-17.5-14PR/2
27×10-12-12PR/2
14.5-17.5-14PR/2
27×10-12-12PR/2
Voltage (V) /
capacitance (Ah)
12/90
12/90
Diesel engine
Model
Xinchai 4D32XG30
Rated
power/rpm
45kW/2500r/min
Max.
torque/rpm
200N·m/(1500-1800) r/min
Displacement
(L)
3.168
Emission grade
China III
