HANGCHA CPCD15 - Page 132

126
Model
CPCD25-X2G92E-RT2
Rated load lifting
capacity kg
2500
Load center distance
mm
500
Max. lift height mm
3000
Free lift height mm
140
Max. lift speed, full
load
mm/s
620
Dip angle of mast,
forward/backward
10°/12°
Max. running speed,
no load
km/h
25
Min. ground
clearance, mm
240
Min. outside
steering radius
mm
2850
Max. gradeability,
full load
%
52
Wheelbase
mm
1880
Weight
4850
Dimensions
(including forks)
(L×W×H)
4305×1557×2390
Tires (front/rear)
12-16.5-14PR/2
27×10-12-12PR/2
Voltage (V) /
capacitance (Ah)
12/90
Diesel engine
Model
Xinchai 4D32X41-002
Rated
power/rpm
36.8kW/2500r/min
Max.
torque/rpm
200N·m/(1400-1600) r/min
Displacement
(L)
3.17
Emission grade
China IV
