HANGCHA CPCD15 - Page 136

130
Model
CPCD15-XG98C-RT4
CPCD18-XG98C-RT4
Rated load lifting
capacity kg
1500
1800
Load center distance
mm
500
500
Max. lift height mm
3000
3000
Free lift height mm
155
155
Max. lift speed, full
load
mm/s
620
620
Dip angle of mast,
forward/backward
10°/12°
10°/12°
Max. running speed,
no load
km/h
25
25
Min. ground
clearance, mm
280
280
Min. outside steering
radius
mm
3200
3200
Max. gradeability, full
load
%
60
60
Wheelbase
mm
1880
1880
Weight
3900
4050
Dimensions
(including forks)
(L×W×H)
4120×1450×2200
4120×1450×2200
Tires (front/rear)
12-16.5-14PR/2
10.0/75-15.3-14PR/2
12-16.5-14PR/2
10.0/75-15.3-14PR/2
Voltage (V) /
capacitance (Ah)
12/90
12/90
Diesel engine
Model
Xinchai 4D29X41-034
Rated
power/rpm
36.8kW/2500r/min
Max.
torque/rpm
175N·m/(1600-1800) r/min
Displacement
(L)
2.85
Emission grade
China IV
