Preface
This manual introduces the safety, operation, transportation, lubrication, general
structure and maintenance procedures of the 1.5t-3.5t rough terrain forklift truck, which
is the latest forklift truck to be developed by our company. The drivers, maintenance staff
and equipment management staff must read and familiarize themselves with this manual
before use.
Some content in this manual may be different from your forklift truck due to continuous
design updates and product improvements.
The illustrations and pictures used in this manual may not be exactly the same as the
detailed structure of your forklift truck.
This manual is also applicable to forklift trucks equipped with attachments.
For any query, please contact the sales company or agent of HANGCHA GROUP CO., LTD.
Standard configuration model
Load center distance mm (in)
500(19.7)
Model
CPCD15-
CPCD18-
CPCD20-
CPCD25-
CPCD30-
Rated load lifting capacity kg/ lb
1500(3300)
1750(3850)
2000(4400)
2500(5500)
3000(6600)
Model
CPCD35-
CPCD40-
CPCD45-
CPCD50-
CPCD55-
Rated load lifting capacity kg/ lb
3500(7700)
4000(8800)
4500(10000)
5000(11000)
5500(12000)
Load center distance mm (in)
600(23.6)
Model
CPCD15-
CPCD18-
CPCD20-
CPCD25-
CPCD30-
Rated load lifting capacity kg/ lb
1350(3000)
1600(3500)
1800(4000)
2250(5000)
2700(6000)
Model
CPCD35-
CPCD40-
CPCD45-
CPCD50-
CPCD55-
Rated load lifting capacity kg/ lb
3200(7000)
3650(8000)
4000(9000)
4500(10000)
5000(11000)
CE model: Optional maximum lift height: 6000 mm
Caution
Bearing Capacity Chart
The chart shows the relationship between the location of
the load center distance and the maximum load. Check
whether the load and the load center distance are within
the allowable range of the Bearing Capacity Chart before
loading. If the load shape is complicated, the heaviest
part should be placed in the center of the fork and close
to the load-backrest.
Note: The model tonnage number displayed below is calculated at a load center distance
of 500mm.
