4 - System setup
64
13. Steering Type:
A. Press to select steering method to be
used when spraying:
“All Wheels” or “Front Wheels”.
B. Press to confirm selections.
14. Press to confirm the settings and
continue.
15. Select Primary Speed Source.
• Self-Propelled sprayer:
Can select between “Hardi” or “Display GPS”
as speed source.
• SARITOR sprayer only:
Always select “Display GPS” as speed source.
÷
NOTE! If “Display GPS” is selected, the Hardi
option must be selected as backup source.
μ
ATTENTION! For additional information see
“Speed Input Settings” on page 89.
Vehicle Offsets: ALPHA evo
Antenna
Steering
All Wheels
Steering Type
Operating Configuration Wizard: Vehicle
Select Vehicle
Offsets
Antenna Location from Rear Axle
Antenna Location from Centerline
Antenna Height from Ground
Dispensing Location from Rear Axle
Dispensing Location from Centerline
Behind
Operating Configuration Wizard: Speed Source
Primary Source
Backup Source
Auxiliary Device Channel
Auxiliary Channel Calibration
Calibrate
Distance
Pulses / 100 ft
Display GPS
Auxiliary Device
Radar
