1st Line Status Icons
All “OK” Information Warning Stop (critical) Variable rate (GPS)
active
Pendulum Locked Pendulum
Unlocked
Track Crab left Track Crab right Track Lock
Track Automatic Track Manual Track Auto mode
not available
AutoSelect
Automatic mode
Line A is ON
Main valve ON
AutoSelect
Automatic mode
Line B is ON
Main valve ON
AutoSelect
Automatic mode
Both lines are ON
Main valve ON
AutoSelect
Manual Mode
Line A is ON
Main valve ON
AutoSelect
Manual Mode
Line B is ON
Main valve ON
AutoSelect
Manual Mode
Both lines are ON
Main valve ON
AutoSelect
Both lines are OFF
Main valve ON
AutoSelect
Automatic mode
Line A is ON
Main valve OFF
AutoSelect
Automatic mode
Line B is ON
Main valve OFF
AutoSelect
Automatic mode
Both lines are ON
Main valve OFF
AutoSelect
Manual Mode
Line A is ON
Main valve OFF
AutoSelect
Manual Mode
Line B is ON
Main valve OFF
AutoSelect
Manual Mode
Both lines are ON
Main valve OFF
AutoSelect
Both lines are OFF
Main valve OFF
Auto mode
Nozzle size
calculated
Auto mode
No flow to
sections
Auto mode
Nozzle size not
calculated
Manual mode
Nozzle size
calculated
Manual mode
No flow to
sections
Manual mode
Nozzle size not
calculated
Increment steps
mode
Nozzle size
calculated
Increment steps
mode
No flow to
sections
Increment steps
mode
Nozzle size not
calculated
Nozzle size not
calculated
