Hardi SMARTCOM ISOBUS UT SW A.2.2 Series User Manual

3 - Description
16
Buttons
÷
NOTE! The location and layout of buttons may differ depending on the general layout of the terminal.
Button E - Optional Function Buttons
These buttons control optional features.
They are activated when the optional functions button (C) is pressed. A submenu with the features appear.
÷
NOTE! The number of levels in the optional functions menu system depends on the number of functions available at
the sprayer - see Optional Functions Menu Tree on next page.
Button A - Increase Volume Rate Button C - Decrease Volume Rate
Button B - Navigation Keys
The navigation keys are initially used for set up in the menu
system.
Button D - Preset Keys
Vital information whilst spraying is quick and easy to
access.
Scroll up selection.
Pressing the button (B) will enter a submenu with the
preset keys.
Enter a submenu or confirm a value. Escape to previous screen.
Scroll down selection. Volume rate.
Press escape to go one step back.
This key appears whenever necessary at respective
menus, etc.
Speed.
Clear a value or a register.
This is normally a physical key in the standard
numeric keypad of the specific Terminal, when
available.
Tank contents.
Area treated.
Total volume sprayed out.
Distance or area remaining.
