Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
DSP PCB ASS'Y
C49 C68 H03-CTKDE0106FK-R CAPACITOR MLCC 10UF 6.3V +- 10% C2012X5R0J106K
C647 C654 C659 C667 C670
C678 C681
CZKII0392BC-R 3n9F 50V X7R K 0603
C649 C655 C662 C668 C672
C679 C683
CZKII0561BC-R CAP CHIP 560P0F +10% -10% 50.0V X7R 0603
C144 CZIKI0104CC-R CAP CHIP 100nF 100V X7R 10% 0805
C32 RS3BB0100NA-R RES,CHIP,10OHM 1/10W +/-5%,0805
Semiconductors
Q113 H03-TRKTA107MNA-R TR-SLPSWA KRA107M PNP
Q112 H03-TRMPSA06NNA-R TR-SLPLF MPSA06 N 500MI0A TO-92 NPN
D801 H03-DURS10040NA-R RS1004 RS-10
D158 D159 H03-DS05GBUSCNB-R DIODE PG05GBUSC
D305 H03-DS05GBUSCNB-R DIODE PG05GBUSC US
D4 D5 D10 D101 D301 H03-DS1S50094NB-R D-SLP 1SS355 35.0V 225MI0A
IC38 H03-IC24LC64ID2-R 24LC64-I/SNG SOIC-8P(150mil) 64K I2C Serial EEPROM
IC7 H03-IC74AHC1G14-R 74AHC1G14 SOT753 Inverting Schmitt trigger
IC2 H03-IC74LC1G1DL-R IC SINGLE SCHMITT BUFFER SN74LVC1G17DBVR SOT(SOT-23)DBV
IC82 H03-IC74LVC254D-R IC SN74LVC257AD SOIC-16 Quadruple 2-Line To 1-Line Data
Selector/Multiplexer With 3-State Outputs
IC16 H03-IC74VC244G5-R IC-LOGIC 74VHC244MX or 74VHC244MX_NL M20B Octal Buffer/Line Driver
with 3-STATE Outputs
IC1 H03-ICBU4051BD3-R 8-channel analog multiplexer /demultiplexer BU4051BCF SOP16
IC14 IC15 IC17 H03-ICBU4094BD3-R IC CMOS BU4094BCF SOP16 8-bit compatible shift / store register
IC4 H03-ICDS1233ADK-R IC 3.3V ECONO RESET DS1233AZ-15+TR SOT-223
IC23 H03-ICK4S1616UC-R K4S161622H-UC60 OR UC80 TSOP50 SDRAM
IC56 H03-ICTC9162CDA-R IC CMOS DIGITAL TC9162CFG SOP28 HIGH VOLTAGE ANALOG
FUNCTION SWITCH ARRAY
Q2 Q4 Q101 Q102 Q103 Q104
Q105 Q106 Q107 Q108 Q109
Q110 Q301
H03-TSKRC107SND-R KRC107S SOT-23 NPN
IC36 IC37 H03-ICC1G125DCK-R IC SINGLE BUS BUFFER GATE SN74LVC1G125DCKT SOT(SC-70)DCKT
IC12 H03-IC24LC256D2-R IC CMOS SERIAL EEPROM 24LC256T-I/SNG SOIC-8P(150MIL)
IC11 H03-IC70F3261E1-R UPD70F3261YGC-8EA-A LQFP100 100-pin general-purpose 32-bit single-
chip microcontroller
IC5 H03-IC74CB3T3D2-R IC SN74CB3T3306DCTR SSOP-8 Dual Bus Switch Voltage Translator
IC39 H03-IC74LC1G1DL-R IC SINGLE SCHMITT BUFFER SN74LVC1G17DBVR SOT(SOT-23)DBV
IC24 IC27 IC81 H03-IC74LVC254D-R IC SN74LVC257AD SOIC-16 Quadruple 2-Line To 1-Line Data
Selector/Multiplexer With 3-State Outputs
IC31 H03-ICCS42528E6-R IC CS42528-CQZ-D QFP64 114 dB, 192 kHz 8-Ch Codec with S/PDIF
Receiver
IC54 H03-ICCS5368BE8-R CS5368-CQZ LQFP48 REV. B0 114 dB, 192 kHz Multichannel A/D
Converters
IC61 IC62 IC63 IC64 IC65 IC66
IC67 IC68 IC69 IC70 IC71 IC72
IC73 IC74 IC75 IC76 IC77 IC78
IC80
H03-ICLM02068D2-R IC-OPERAMP NJM2068M-TE1 DUAL OP-AMP SOP8
IC25 H03-ICM317TO252-R IC 3-TERMINAL ADJUSTABLE POS VOL REG NJM317DL1-TE1 TO-252
IC6 H03-ICNJM2872D0-R NJM2872AF33-TE1 3.3V SOT-23(MPT5) LOW DROPOUT VOLTAGE
REGULATOR
US
IC55 H03-ICS4391AKZZ-R CS4391A-KZZ SOP20 24-BIT, 192 kHz STEREO DAC WITH VOLUME
CONTROL
IC34 IC35 H03-ICSN74HCU04-R IC SN74HCU04D HEX INVERTER
IC21 H03-ICTMS320DA6-R IC FLOATING-POINT DSP TMS320D610A PQFP208
IC33 H03-ICTUSB320EB-R ICTUSB3200A TQFP52 USB Streaming Controller (STC)
IC32 H03-ICXMDIC00E8-R IC DIGITAL TRANCEIVER XMDIC QFP48 US
D306 H03-DS05GBUSCNB-R DIODE PG05GBUSC US
D1 D3 D6 D7 D8 D9 D103 D104
D304 D508
H03-DS1S50094NB-R D-SLP 1SS355 35.0V 225MI0A
Q1 Q3 Q201 Q303 H03-TSKRC107SND-R KRC107S SOT-23 NPN
IC22 H03-ICM29W160ET-R IC FLASH MEMORY M29W160ET TSOP48 ST
AVR645
harman/kardon
102
