Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
DSP PCB ASS'Y
R638 R641 R653 R658 R668
R667 R688
RS3AD0562NA-R RMGCFMIC 5K6 OHM +5% 0603
R327 R700 RS3AD0681NA-R RES CHIP,680R 1/16W +/-5%,0603
R572 RS3AD0682NA-R RMGCFMIC 6K8 OHM +5% 0603
R46 R47 R302 R306 R310
R315 R325 R323 R384
RS3AD0750NA-R RMGCFMIC 75R0 OHM +5% 0603
R501 R504 R540 R541 R570
R600 R603
RS3AD0821NA-R RMGCFMIC 820R0 OHM +5% 0603
R56 R57 R61 R62 R63 R64
R65 R66
RS3AD0823NA-R RES,CHIP 82K,1/16W,+/-5%,0603
R12 R13 R753 R754 RS3BB0101NA-R RES,CHIP,100 OHM 1/10W +/-5%., 0805
R360 RS3AD0105NA-R RES CHIP 1M 1/16W +5% 0603
R389 RS1AD1371NA-R RES.CHIP,1.37K OHM ,1/16W,+/-1%,0603
R715 RS3BB0150NA-R RES,CHIP,15 OHM 1/10W +/-5% 0805
BD7 BD11 BD12 RS3BB0000NA-R RES CHIP 0 OHM +5% 100MI0W 0805
R140 R141 R142 RS3AD0220NA-R RES CHIP,22R 1/16W +/-5%,0603
R58 RS3AD0470NA-R RMGCFMIC 47R0 OHM +5% 0603
R45 RS3AD0124NA-R RES CHIP,120K 1/16W +/-5%,0603
RS21 RS22 RN3AY0220NA-R RES NETWORK RCA 22OHM 1/16W 5% CN34JT220
R17 R20 R738 R739 R750
C340
RS1AD0100NA-R RES CHIP 10 OHM 1/16W 1% 0603
R32 RS1AD3321NA-R RES CHIP 3.32K OHM 1/16W 1% 0603
R33 RS1AD4751NA-R RES.CHIP 4.75K 1/16W +/-1% 0603
R126 R127 R317 R320 C341
C334 C335 C336
RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603
R24 R54 R68 R206 R207 R233
R234 R331 R332 R748 R820
RS3AD0100NA-R RMGCFMIC 10R0 OHM +5% 0603
R2 R30 R74 R382 R383 R745
R764
RS3AD0101NA-R RES CHIP,100R 1/16W +/-5%,0603
R7 R8 R9 R31 R354 R755
R756 R757 R860
RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603
R25 R26 R36 R39 R40 R101
R236 R735 R736
RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603
R288 RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603 US
R287 RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603 EU
R29 R38 R43 R147 R348 R349
R350 R351 R355
RS3AD0104NA-R RES CHIP,100K 1/16W +/-5% ,0603
R632 R642 R651 R660 R669
R679 R686 R697
RS3AD0122NA-R RMGCFMIC 1K2 OHM +5% 0603
R333 RS3AD0152NA-R RES CHIP 1K5 1/16W +5% 0603
R257 R259 R261 RS3AD0153NA-R RES CHIP,15K 1/16W,+/-5%,0603.
OR14 R212 R213 R214 RS3AD0182NA-R RES CHIP,1.8K,1/16W,+-5%,0603.
R696 RS3AD0183NA-R RMGCFMIC 18K0 OHM +5% 0603
R718 R727 RS3AD0202NA-R RMGCFMIC 2K0 OHM +5% 0603
R79 RS3AD0220NA-R RES CHIP,22R 1/16W +/-5%,0603
R334 R335 RS3AD0270NA-R RES,CHIP 27 OHM 1/16W +/-5% 0603
R527 R528 R529 R530 R566
R567 R568 R569 R596 R597
R598 R599 R626 R627 R628
R629
RS3AD0331NA-R RMGCFMIC 330R0 OHM +5% 0603
R220 RS3AD0392NA-R RMGCFMIC 3K9 OHM +5% 0603
R716 R725 RS3AD0432NA-R RMGCFMIC 4K3 OHM +5% 0603
R163 R168 RS3AD0471NA-R RMGCFMIC 470R0 OHM +5% 0603
R67 R146 R148 R201 R232
R329 R330 R336 R337 R630
R640 R649 R657 R666 R676
R684 R694 R721 R729
RS3AD0472NA-R RES CHIP,4K7 1/16W +/-5%,0603
R102 R511 R512 R552 R553
R582 R583 R612 R613 R758
R759
RS3AD0473NA-R RES CHIP,47K 1/16W +/-5%,0603
R37 RS3AD0474NA-R RMGCFMIC 470K0 OHM +5% 0603
R635 R644 R654 R662 R673
R681 R690 R701 R722 R731
RS3AD0561NA-R RES CHIP,560R 1/16W +/-5%,0603
R634 R647 R648 R661 R671
R683 R689
RS3AD0562NA-R RMGCFMIC 5K6 OHM +5% 0603
AVR645
harman/kardon
104
