Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
DSP PCB ASS'Y
R695 RS3AD0681NA-R RES CHIP,680R 1/16W +/-5%,0603
R73 BD38 BD44 RS3BB0000NA-R RES CHIP 0 OHM +5% 100MI0W 0805
R505 R509 RS3BB0101NA-R RES,CHIP,100 OHM 1/10W +/-5%., 0805
R19 R22 R59 R60 R75 R76
R77 R78 R368 R370 R371
R372 R373 R374 R375 R376
R377 R386 R740 R741 R742
R743 R744
RS3AD0470NA-R RMGCFMIC 47R0 OHM +5% 0603
R734 RS1BB022ANA-R RES.CHIP,2.2 OHM ,1/16W,+/-1%,0805
R777 RS3AD010ANA-R RES CHIP,1R 1/16W +/-5%,0603
R1 R752 RS3AD0221NA-R RMGCFMIC 220R0 OHM +5% 0603
R23 RS3AD0390NA-R RES,CHIP 39 OHM 1/16W +/-5% 0603
R231 RS3AD0750NA-R RMGCFMIC 75R0 OHM +5% 0603
R53 RC3DI010AIN-R RCF 1R0 OHM +5% 250MI0W
Miscellaneous
BD4 BD9 BD21 BD25 BD26
BD27 BD28 BD32 BD33 BD35
BD37 BD39 BD40 BD41 BD51
BD52 BD53 L706 L802
H03-FB3012012CF-R FCM2012CF-301T04 0805
BD5 BD36 H03-FB3012012CF-R FCM2012CF-301T04 0805 US
BD24 H03-FYACF333TNN-R FILTER ACF451832-333-T
BD81 H03-FB2522012HF-R FCM2012HF-252T02 2500ohm SURFACE MT 2012
BD6 BD8 BD10 BD22 BD31
BD49 BD54
H03-FB3012012CF-R FCM2012CF-301T04 0805
Y1 H03-OSXNL4515B0-R CRYSTAL 45.1584MHz 22p SO22320D5-45.1584-T&R US
NJ36 H03-SOUSB5005K0-R AU6-EC-005K0
NJ35 H03-SOUSB45810B-R JACK R41-5810B (Mitsumi) XM/DT connector US
P091 H03-ICLM19CIZIE-R IC TEMPERATURE SENSOR LM19CIZ 2.4V TO-92
PC11 H03-ICPC17T10B1-R IC PHOTOCOUPLER PC-17T1 DIP4 KODENSHI
Y101 H03-OSCEM05M0RU-R CERAMIC RESONATOR CSTLS_G 5.0MHz
Y201 H03-OSCEM24M5RU-R VCXO 24M576 HZ +50 PPM -50 PPM 0 OHM 3.3V
Y301 H03-OSX06M0HZ00-R CRYSTAL 6MHz 2P WOOIN HC-49/S_22PF
K400 H03-RLL0516632B-R RELAYPWR 5.0V 166.0OHM 1.0A 24.0V
NJ12 H03-SORA40RSANN-R JACK RCA 4P JB040131ZN GN BN PP TA
NJ11 H03-SORA40RSCNN-R JACK RCA 4P JB040131QN WH BU RD GY
NJ31 NJ32 NJ33 H03-SORX220751N-R YKC22-0751N
NJ34 H03-SOTX220750N-R YKC22-0750N
N931 H03-WE03B012000-R WIRE ASS`Y UL1007#26 120MM 2.0MM 3P WHT
N707 H03-WN02SD00000-R CONN 2.5MM 2 MA ST NAT 5267-02A 0 0 US
P711 P712 H03-WN03SE00000-R CON 3.96MM PITCH MOLEX 35313-0310
P707 H03-WN04AB100WH-R CONN WAFER 2.0MM 4P 35237-0410 WHT
P704 H03-WN05SB00000-R CONNECT 2.0mm 5P GIL-S-5P-S2T2-EF
N104 H03-WN07AB100WH-R CONN WAFER 2.0MM 7P 35237-0710 WHT
P815 H03-WN07SB100WH-R CONN WAFER 2.0MM 7P 35336-0710 WHT
N714 H03-WN09AB100WH-R CONNECT WAFER 2.0mm 9P 35237-0910 WHT
P703 H03-WN09SB00000-R CONNECT 2.0mm 9P GIL-S-9P-S2T2-EF
P713 H03-WN09SB100WH-R CONNECT WAFER 2.0mm 9P 35336-0910 WHT
N706 H03-WN15AB100WH-R CONNECT WAFER 2.0mm 15P 35237-1510 WHT
N705 H03-WN16AB100WH-R CONNECT WAFER 2.0mm 16P 35237-1610 WHT
P714 H03-WN16DI00000-R GF120-16S-TS 1.25mm 16P
N702 N710 H03-WN19AB00000-R CONN 2.0MM 19 MA R NAT SOCKET MOLEX 35237-1910
P701 H03-WN22DI00000-R GF120-22S-TS 1.25mm 22P
