Page 14
CDi DriveCore Series Operation Manual
Conguring the Amp
Assigning Input Sources
Input sources can be assigned from the Input Source screen (see Figure 14). The default
preset (Preset 1) is configured with all analog inputs feeding their respective output
channels.
To assign input sources manually:
1� From the Home screen, press the MENU button.
2� Select the "Configure Amplifier" option from the menu using the ENCODER.
3� Select the "Input Source" option.
4� Use the ENCODER to select each input channel block and edit the input channel
source assignment.
TIP: When assigning a BLU link input channel, the "BLU" option must first be
selected from the list, then the ENCODER must be pressed. Turning the ENCODER
will then select the desired BLU link channel from the list.
5� When done, select "Done" at the bottom of the screen.
Available options:
• Analog 1
• Analog 2
• Analog 1+2 (mono summed)
• Analog 3*
• Analog 4*
• Analog 3+4* (mono summed)
• Any available BLU link channel**
• None
For information on assigning input sources in Audio Architect, see "Assigning Input Sources in Audio Architect" on page 36.
*Channel 3 and 4 options available in 4-channel CDi DriveCore models only.
**BLU link options available in BLU link CDi DriveCore models only. BLU link channels 129-256 not available when using a BLU link bus operating at a
96kHz sample rate.
Figure 14: Input Source screen
