Page 49

CDi DriveCore Series Operation Manual

Using HiQnet Audio Architect

Programming BSS Contrio Ethernet Wall Controllers

The BSS Audio Soundweb Contrio Ethernet wall controllers can be used to control many of the parameters and functions in a CDi DriveCore ampliﬁer. At

the time of this writing, there are four Ethernet Contrio controller models available. Contrio controllers come in black or white, with US and EU versions

available (black US models shown).

EC-V EC-4B EC-4BV EC-8BV

To program a Contrio Ethernet wall controller:

1� Launch Audio Architect.

2� The Contrio controller must be on the same network as the CDi DriveCore amp and the computer running Audio Architect. If using a DHCP server,

the network settings should be automatically conﬁgured correctly. If using static IP addressing, use the NetSetter application to conﬁgure the Contrio

controller's network settings. See "Conguring the Network using NetSetter" on page 25 for more information.

3� If the CDi DriveCore amp and Contrio wall controller are already visible in Audio Architect's Room window, skip to step 5. If they are not visible, select

the "Devices" tab in the lower-left corner of the Main Audio Architect window. Any detected HiQnet devices will appear under the "Discovered" menu

tree on the left.

4� Add the Contrio controller to the Audio Architect venue by dragging it from the "Discovered" menu tree to the Room window. Add the CDi DriveCore

amp as well if it has not already been added.
