Page 44
CDi DriveCore Series Operation Manual
Using HiQnet Audio Architect
Input/Output Delay Panels
The CDi DriveCore Series amplifiers offer an Input (pre-Crossover) and Output (post-
Crossover) Delay for each channel. The Output delay is typically used for driver alignment
and provides up to 100ms of delay time per channel. The Input Delay provides up to 1 second
of additional delay time and can be used for delaying the system to the stage backline, delay
fills, or whenever more delay time is required than the Output Delay has to offer. Delay can be
adjusted in seconds, feet, or meters (see Figure 57).
The Input Delay panel can be accessed by clicking the Input Delay button, and the Output Delay panel can be accessed by clicking the Output Delay
button from the Main CDi DriveCore Control panel (see Figure 56).
NOTE: If speaker tunings have been configured for a channel, the Output Delay panel will not be available for that channel.
Figure 57: Input Delay panel
Figure 56: Input and Output Delay buttons
